IntelliVue MX750
Bedside patient monitor
IntelliVue MX750
Bedside patient monitor
The IntelliVue MX750 is the critical care workhorse of the IntelliVue family, covering a wide range of intensive care and anesthesia use cases and applications. Featuring direct access to hospital applications via HTML5, Citrix, and optional integrated PC, the monitor is also designed to support cybersecurity features such as node authentication, network data encryption, print report encryption and device data encryption, and includes a built-in RFID/NFC card reader.
Features
People-focused design
IntelliVue MX750 and MX850 patient monitors have been recognized with the prestigious iF Product Design Award. Designed with robustness and longevity in mind, they have been recognized as both patient- and user-friendly with a professional appearance. The iF Design Award recognizes manufacturers and designers for outstanding achievement in design.
Integrated PC (iPC) option
The iPC expands your access to comprehensive patient information from sources such as IntelliSpace Critical Care and Anesthesia (ICCA). And because the iPC uses a standard Windows® operating system, it is compatible with your IT environment, giving you access to clinical informatics solutions from across your hospital network.
2020 DFA Design for Asia Awards Bronze Award
IntelliVue MX750 and MX850 patient monitors were recognized with the 2020 DFA Design for Asia Bronze Award for Hong Kong, in the Product & Industrial Design category. This award assesses the overall design excellence, innovation, usability, aesthetic, sustainability, impact in Asia, as well as commercial and societal success.
Specifications
- Physical Specifications
- Display size
- 19" inch widescreen
- Display resolution
- 1920 x 1080
- Display type
- Full HD with projected capacitive touch (pCAP)
- Number of waves per display
- 12 waves (max)
- Module rack slots
- Up to 8 (with 2 FMX-4 racks)
- Applications
- Native web app capability without iPC
- Video
- Encrypted video via LAN to
- Active Display¹ or XDS
- Alarms
- Remote via LAN (encrypted) to
- Active Display¹ or XDS
- Independent display
- Number of independent displays
- 1 Active Display¹ or XDS
- Cybersecurity measures
- User ID/authentication
- via RFID
- Node authentication
- via certificates; network data, print reports and file system encryption
- Native Citrix client
- Native Citrix client
Related products
- The IntelliVue MX850, with its multi-display and multi-user capabilities, is built for the highest-acuity patients and the most demanding interventions, such as cardiothoracic or transplant surgery. Featuring direct access to the hospital applications via HTML5, Citrix, and optional integrated PC, the monitor is also designed to support cybersecurity features such as node authentication, network data encryption, print report encryption and device data encryption, and includes a built-in RFID/NFC card reader.
- IntelliVue AD75 Active Display provides an independent display with real-time guaranteed alarming capability for use with specific IntelliVue monitors. The IntelliVue AD75 Active Display contains an optically bonded 19" (469 mm) LCD (TFT)display with predicted capacitive (pCap) touch technology, within a housing similar to MX750 patient monitor. The IntelliVue AD75 Active Display connects to a host monitor via a LAN connection. The display provides 4 USB ports for connecting USB HID compatible pointing devices. The front of the display has a built-in Contactless ID and Communication device utilizing RFID technology. When connected to a patient monitor, the IntelliVue AD75 Active Display can show the same number of waveform channels as the monitor itself. When mounted close to the monitor, the alarm sounds on the display can be disabled. When mounted remotely the patient monitor in the room can be silent, while IntelliVue AD75 Active Display takes over the sounding of alarms.
- PIC iX is an integral part of the Philips enterprise monitoring ecosystem, spanning high-, mid-, low and specialty acuity settings. It enables patient data to flow throughout these care areas by bringing in data from Philips and non-Philips devices across care settings. You can streamline workflows by helping clinicians to detect and respond to patient changes wherever they are in the hospital and protecting the security of patient data via stringent medical industry standards. PIC iX integrates into your existing infrastructure so you can standup a new unit in less time and be prepared for future changes in care delivery. And since scalability and flexibility is critical to your operations, we offer a remote, device operational management solution, enabling IT and biomed technicians to improve system uptime, track performance, and lower operations expenses.
Disclaimer
May not be available in all geographies, please see your Philips representative for complete portfolio availability.
